High-Brightness Ultra-Wide Display with Low-Power LED Backlight for Space-Constrained Integration
The 150ML-N15HIG is designed for installations requiring a long, narrow display area. Its 3:1 format combines 1000 cd/m² brightness, a slim bezel and 70,000-hour backlight MTBF with 6–36 VDC input and up to 21 W power consumption. The compact stretched form factor supports integration into signage, transportation systems, vending equipment and custom industrial displays.
Speification
15-inch 1000-nit industrial stretched LCD monitor
| Display Size | 15 inch |
| Display Resolution | 1280 × 252 |
| Brightness | 1000 cd/m² |
| Display Type | Industrial Stretched TFT-LCD |
| Aspect Ratio | 3:1 |
| Viewing Angle | 85°/85°/80°/80° typ. |
| Operating Temperature | -10°C to 60°C |
| Input Interface | 1 × HDMI, JST PUDP-14V-S, 14-pin |
| Input Voltage | 6–36 VDC |
| Power Consumption | Max. 21 W @ 1000 nits |
| Contrast Ratio | Typ. 1000:1 |
| Display Colors | 16.7 million, 72% NTSC |
| Response Time | Typ. 6.5 ms |
| Active Display Area | 376.50 × 71.20 mm |
| Pixel Pitch | 0.294 × 0.294 mm |
| Backlight | LED |
| Backlight MTBF | 70,000 hours |
| Overall Dimensions | 398.40 × 96.90 × 40.80 mm |
| Storage Temperature | -20°C to 70°C |
| Operating Humidity | 20%–90% |
